MIL-PRF-62122E
TABLE III. Order of first article test for cable and plug assembly part number 11682336 1/, 2/.
Subsequent test
Title
Requirement
Procedure
Requirement
Procedure
Specimen 1
Materials and construction
3.2 and 3.3
4.7.1
--
--
Defects (see 4.7.2 and
3.3, 3.5 and
4.7.2
--
--
table IV)
3.6
Continuity
3.4.1.1
4.7.3.1
--
--
Current, continuous
3.4.1.2
4.7.3.2
--
--
Current, overload
3.4.1.3
4.7.3.3
--
--
Resistance to low
3.4.2.5
4.7.4.5
--
--
temperature
Resistance to ozone
3.4.2.7
4.7.4.7
--
--
exposure
Resistance to petroleum
3.4.2.3
4.7.4.3
--
--
products
Current, continuous
--
--
3.4.1.2
4.7.3.2
Current, overload
--
--
3.4.1.3
4.7.3.3
Dielectric withstanding
--
--
3.4.1.4
4.7.3.4
voltage
Contact resistance
--
--
3.4.1.5
4.7.3.5
Mating
--
--
3.4.2.4
4.7.4.4
Specimen 2
Continuity
3.4.1.1
4.7.3.1
--
--
Current, continuous
3.4.1.2
4.7.3.2
--
--
Current, overload
3.4.1.3
4.7.3.3
--
--
Fungus resistance
3.4.2.6
4.7.4.6
--
--
Dielectric withstanding
3.4.1.4
4.7.3.4
--
--
voltage
Specimen 3
Mating
3.4.2.4
4.7.4.4
--
--
Continuity
3.4.1.1
4.7.3.1
--
--
Current, continuous
3.4.1.2
4.7.3.2
--
--
Current, overload
3.4.1.3
4.7.3.3
--
--
Clamp strength
3.4.3.2
4.7.5.2
--
--
Crimp strength
3.4.3.1
4.7.5.1
--
--
1/ Plugs and receptacles used in testing the cable and plug assemblies shall have passed the
tests as specified in table II a and II b.
2/ Cable assemblies part number 11682337 shall be tested as part of cable and plug assembly
as specified in table III.
